16 Jupyter
Prerequisites (read first if unfamiliar): Chapter 14, Chapter 15.
See also: Chapter 17, Chapter 7, Chapter 28.
Purpose
Jupyter notebooks are an effective medium for exploratory analysis because they combine code, results, and narrative. The same flexibility can also create confusion: wrong working directories, out-of-order execution, hidden state, and notebooks that cannot be reproduced. This chapter teaches novices how to launch Jupyter correctly, navigate files, use cells effectively, run shell commands safely, and adopt notebook discipline so work remains interpretable and reproducible.
Learning objectives
By the end of this chapter, you should be able to:
Launch Jupyter Notebook or JupyterLab from the command line in the correct folder.
Diagnose the common “Jupyter has no files” problem (wrong working directory).
Explain kernels, sessions, and the difference between Notebook and JupyterLab.
Use cell types (code/markdown/raw), move cells, and manage execution order.
Use IPython magics and run shell commands inside a notebook safely.
Structure a notebook for readability: headings, narrative, and controlled outputs.
Make notebooks reproducible: restart-and-run-all, environment capture, and data provenance.
Convert notebooks into scripts/reports when appropriate.
Running theme: notebooks are documents and programs
A notebook should read like a report and execute like a program. The discipline is to ensure both.
16.1 Mental models: what Jupyter is doing
You will encounter two flavors of Jupyter and they are sometimes confused with each other. Jupyter Notebook (often called “classic”) is the original single-document interface — one notebook per browser tab, no built-in file browser, very simple. JupyterLab is the newer multi-document environment that gives you a file browser sidebar, multiple notebooks open as tabs, integrated terminals, and side-by-side panes. Most modern courses use JupyterLab. Both flavors run on the same underlying machinery, so anything you learn about kernels and execution state applies to either.
That underlying machinery has three pieces, and you should be able to name all three when something goes wrong. The server is the process you start when you run jupyter lab from the terminal — it listens on a port (usually localhost:8888) and is the actual program your browser is talking to. The browser UI is the HTML interface where you edit cells, click Run, and see output; it is just a thin shell around the server. The kernel is a separate process that runs your code — for Python notebooks it is a Python interpreter, but Jupyter also supports R, Julia, Bash, and others. When you press Shift+Enter on a cell, the browser sends the code to the server, the server hands it to the kernel, the kernel runs it, and the result comes back through the same chain.
You type in a cell → browser → Jupyter server → kernel → result back up the chainThe single most important thing to internalize about notebooks is that the kernel keeps state across cells. When you assign df = pd.read_csv("data.csv") in one cell, that variable lives in the kernel’s memory until you restart it. You can run cells out of order, redefine variables, delete cells whose results are still in memory, and end up in a situation where the notebook on screen does not match the state in the kernel — a phenomenon called hidden state. “It works on my notebook” almost always means “it works against the specific hidden state in my kernel right now,” and the only reliable way to find out whether your notebook is actually correct is to Restart Kernel and Run All and watch every cell execute from a clean slate. Build that habit early.
16.2 Launching Jupyter the right way
The single rule that prevents most “Jupyter cannot find my files” frustration is: always launch Jupyter from your project’s folder. The folder you are in when you start the server becomes Jupyter’s root — the file browser shows the contents of that folder and nothing above it. If you launch from your home directory, you will see all of your home; if you launch from the wrong project, you will see the wrong project; if you launch from Downloads, you will see Downloads.
The full opening sequence for a project is three commands:
cd ~/Courses/INFO-3010/Project # 1. go to the project root
source .venv/bin/activate # 2. activate the project's environment
jupyter lab # 3. start the server
Each command matters. The cd puts Jupyter in the right folder. Activating the venv ensures Jupyter starts with your project’s interpreter and packages, not the system Python. And jupyter lab (or jupyter notebook for the classic interface) is what actually launches the server. After running them, your default browser opens with the JupyterLab UI, and the file browser on the left should show the contents of your project — data/, notebooks/, src/, the README. If it shows something else, stop and try again from the correct folder.
To verify you are in the right place once Jupyter is up, run a single cell at the top of any notebook:
import os
print(os.getcwd())If the path it prints is your project root, you are good. If it is anything else, close the server (Ctrl+C in the terminal) and relaunch from the right place. Some people leave a PROJECT_ROOT.txt file in their project root specifically so they can ls for it from inside a notebook as a quick “am I in the right place” check.
16.3 The common failure: “Jupyter shows no notebooks”
The most common Jupyter complaint is some variant of “I opened JupyterLab and my files are not there,” or “my notebook cannot find data/input.csv even though I can clearly see it in Finder.” Both are usually the same problem: the Jupyter server is running in a different folder than the one you think it is. The file browser shows whatever folder the server was launched in, and your code’s relative paths resolve relative to that folder — so if the server is in the wrong place, both symptoms appear at once.
There are three common ways to end up here. The first is launching Jupyter from your home directory or Downloads instead of your project folder. The second is having multiple Jupyter servers running at once on different ports — you click an old browser tab and end up looking at a different server than you just started. The third is launching from the wrong environment, so the kernel paths and packages do not match what your project expects.
The fix checklist is short. First, stop the misbehaving server: go back to the terminal where you launched it and press Ctrl+C (twice if it asks you to confirm). Close the browser tab. Second, in the terminal, cd into the correct project folder and confirm with pwd. Third, activate the correct environment and run jupyter lab again.
When a notebook’s import pandas fails with ModuleNotFoundError even though you just pip install-ed pandas, the kernel is almost certainly running a different Python than the one you installed into. From inside the notebook, run import sys; print(sys.executable) — the path should contain your project’s .venv/. If it does not, use the kernel picker (top-right of JupyterLab) and pick the kernel whose name matches your environment.
If your venv’s kernel is not in the picker at all, register it explicitly: with the venv activated, run python -m pip install ipykernel then python -m ipykernel install --user --name project-venv --display-name "Python (project-venv)". Reload JupyterLab and the new kernel will appear.
Fourth, if you still see the wrong files, you may have another Jupyter server running on a different port — jupyter server list will show every running server, and you can shut down any stragglers. Finally, get into the habit of putting a “where am I” check at the top of every notebook so this is always visible:
import os
print("cwd:", os.getcwd())
print("contents:", sorted(os.listdir("."))[:10])That single cell turns “Jupyter is broken” into a clear, immediately diagnosable state.
16.4 Notebook mechanics: cells and execution
Cell types
Every cell in a Jupyter notebook has a type, and the type determines what the cell does when you run it. There are only three, and you will use two of them almost all the time.
A Code cell holds Python (or whatever language the kernel speaks) and is sent to the kernel for execution when you run it. Whatever the last expression in the cell evaluates to is displayed below the cell as its output, alongside anything the code explicitly printed. Code cells are the only cells that actually compute anything — they are where the work happens.
A Markdown cell holds text, not code. When you run a markdown cell, Jupyter renders it as formatted prose: headings become headings, code spans become monospace, lists become lists, and equations written in LaTeX syntax ($x^2$) become typeset math. Markdown cells are how a notebook becomes a document — the paragraphs between your code cells that tell a reader what you are doing and why.
df.head() and its rendered DataFrame output. The cell below it is a markdown cell whose source contains a heading and a short paragraph, and which is rendered as formatted prose.
A Raw cell is passed through without rendering or execution. You will almost never need one as a student; they are mainly used when converting a notebook to another format (like LaTeX or a slide deck) and you need to include material that should not be interpreted by Jupyter. Leave them alone unless a specific tool tells you to use one.
[code cell] → sent to kernel → produces output below the cell
[markdown cell] → rendered as HTML → produces formatted text below
[raw cell] → passed through untouched (rarely needed)You can change a cell’s type with the dropdown in the toolbar or with the keyboard shortcuts Y (code) and M (markdown) while the cell is selected in command mode.
Running cells
There are several ways to run a code cell, and each is appropriate in different moments. Shift + Enter runs the current cell and moves focus to the next one — this is the default for “I am working through the notebook top to bottom.” Ctrl + Enter (or Cmd + Enter on macOS) runs the current cell without moving focus, which is what you want when you are iterating on a single cell, tweaking the code, and running it again. Alt + Enter runs the current cell and inserts a fresh empty cell below it.
When you want to run more than one cell at a time, the menu offers Run All (the entire notebook), Run All Above (everything from the top down to the current cell), and Run All Below (the current cell and everything after). Run All is the one you should run every time you finish a meaningful chunk of work — it is your reproducibility check.
Shift + Enter → run and advance (default)
Ctrl + Enter → run and stay (iteration)
Alt + Enter → run and insert new cell below
Menu: Run → Run All Cells (from the top)
Menu: Run → Run All Above Selected (up to the current cell)When a cell is running too long or has gotten stuck, you have two escalation levels. Interrupt (the square “stop” button, or I, I in command mode) asks the kernel to stop the current cell — the kernel keeps running, variables stay in memory, and only the cell is cancelled. Restart (the circular arrow, or 0, 0 in command mode) kills the kernel entirely and starts a fresh one; all variables are gone. Interrupt first, always, and only restart if interrupt does nothing. Restart wipes every piece of state you had built up in the session, so use it deliberately, not reflexively.
The most important diagnostic in the notebook UI is the little number in square brackets that appears next to each executed code cell. That is the execution count, and it increments by one every time any cell is run. If you look at the counts down a notebook and see [1] [2] [3] [4], the notebook was run top to bottom and in order — what you see in the outputs is what the code would produce on a clean run. If you see [3] [1] [7] [2], the cells were run out of order, and what you see is a collage of states that may never have existed simultaneously. Before trusting any notebook — yours or someone else’s — glance down the left margin and confirm the numbers go in order.
Moving and organizing cells
A notebook is not just a sequence of cells — it is a document, and like any document, the order of its sections matters. When you reorganize the analysis (promote a side exploration into the main narrative, push a helper calculation out of the main flow) you should physically move the cells so that the story you are telling matches the code that is running. Cells move with the up and down arrow buttons in the toolbar, with drag-and-drop in JupyterLab, or with the keyboard shortcuts Esc, K (move up) and Esc, J (move down).
As a notebook grows, the single highest-leverage organizing move is to use markdown headings. A cell containing # Loading the data or ## Cleaning decisions becomes a heading in the rendered notebook and appears in the table of contents panel on the left. With even four or five headings, a hundred-cell notebook becomes navigable — you can jump from “Imports” to “Cleaning” to “Modeling” to “Results” in one click, instead of scrolling. A reader who opens your notebook and can skim the table of contents will immediately understand its structure; a reader faced with a hundred undifferentiated cells will give up.
The one rule of cell order that you should treat as inviolable is: keep imports and configuration near the top. Every notebook should begin with a small block of imports (import pandas as pd, etc.), a path-and-parameter setup cell, and a smoke-test cell (see Chapter 17), and nothing else should come before them. If an import cell is buried five pages down, anyone running the notebook from the top will hit a NameError before they ever get there. All the imports, all at the top, once.
Output management
Every code cell’s output is stored inside the notebook file, which has two consequences worth understanding. First, the notebook gets bigger every time a cell produces output — a cell that prints 10,000 rows of a DataFrame adds the text of 10,000 rows to the file on disk. Second, that output is what shows up in git diffs, in file previews, and in anyone’s browser when they open the notebook. A notebook that prints entire datasets is slow to load, painful to scroll, and impossible to review.
The habit that prevents this is to summarize instead of dump. Do not finish a cell with df to see the whole table; finish it with df.head(), df.sample(5), or df.describe(). Do not print a list of every filename in a folder; print len(files) and files[:5]. Do not save a 2000×2000 image inline; save it to figures/ and reference it from a markdown cell.
# Avoid: dumps the entire dataset into the notebook output
df
# Prefer: just enough to see what's there
df.head()
df.shape # (rows, cols) — almost always what you want
df.describe() # summary statisticsThe supporting habit is to clear and re-run outputs before committing a notebook to version control. In the menu, Cell → All Output → Clear wipes every cached output. Then Run All executes the notebook from scratch, producing exactly the outputs your current code would produce on a clean run. Two benefits: the notebook you commit is reproducible (what you see is what the code does), and the file is dramatically smaller because you have gotten rid of any stale outputs from older experiments.
16.5 Running shell commands inside notebooks (responsibly)
Why this is useful
Most of the time you think of a Jupyter notebook as a place to run Python, but the kernel is also willing to hand the occasional line off to the shell. This is surprisingly handy for the small housekeeping tasks that surround every analysis: checking whether a data file arrived, listing the contents of an output folder, downloading a CSV the script needs, or running a command-line tool like git or pandoc as part of a pipeline. Being able to do these checks in-line with your analysis keeps the whole story in one place, instead of forcing you to flip between the browser and a terminal.
The most common reason you will want it is quick file-system checks — confirming that data/raw/sales.csv exists before trying to read it, listing the files in data/processed/ to verify a previous step produced what it was supposed to, or seeing how big an output file turned out to be. These are exactly the kinds of checks you would otherwise run in a terminal window, but having them inside the notebook means the diagnostic is captured alongside the code that depends on it.
The second reason is lightweight automation — downloading a file with curl, decompressing an archive with unzip, or running a command-line tool (like pandoc to convert a report) as part of the notebook flow. This is appropriate when the command is small, deterministic, and not destructive. For anything bigger — a multi-step pipeline, a long-running training job, a batch of runs over many inputs — a script is almost always the right answer.
Two mechanisms: “bang” and magics
Jupyter offers two ways to run a shell command inside a code cell, and they look different on purpose. The first is the bang prefix — a single exclamation mark at the start of a line tells Jupyter “hand this line off to the shell and show me whatever it prints.” You can mix bang lines with regular Python in the same cell:
# A mix of Python and shell in one cell
import pandas as pd
!ls -lh data/raw/ # shell: list the raw data folder
df = pd.read_csv("data/raw/sales.csv") # Python: load it
!wc -l data/raw/sales.csv # shell: how many lines did we just read?The second mechanism is magics — commands prefixed with % (for one line) or %% (for a whole cell) that Jupyter itself understands. Line magics do one specific thing (%cd to change directory, %env to show environment variables); cell magics change what the entire cell does (%%bash makes the whole cell a shell script, %%time times a cell’s execution). Magics are built into IPython and Jupyter, not into the shell, so they work identically on every platform — unlike a bang prefix, which passes through to whatever shell your operating system uses.
%cd ~/Courses/INFO-3010/Project # change the kernel's working directory
%pwd # print it
%env API_URL # show the value of an env var%%bash
# Whole cell runs as a bash script; no ! prefixes needed
for f in data/raw/*.csv; do
echo "$f: $(wc -l < "$f") lines"
doneWhen should you prefer a magic over a bang? For anything that involves multiple shell lines — loops, conditionals, pipelines spanning several commands — %%bash is cleaner than prefixing every line with !. For single ad-hoc checks, a ! line is fine.
Common magics for students
A handful of magics cover almost everything a student will ever need, and all of them are worth knowing by name so you can recognize them when you see them in other people’s notebooks.
%cd <path>changes the kernel’s working directory. Use this sparingly — it is better to launch Jupyter from the project root and nevercdat all — but it is occasionally the right tool when you cannot control how the server was launched.%pwdprints the kernel’s current working directory. The first thing to run when you suspect a path problem.%lslists the contents of the current directory. Equivalent to!lsbut cross-platform.%env VAR=valuesets an environment variable for the kernel, and%env VARprints its current value. Useful for configuring things likeDATABASE_URLwithout leaving the notebook.%time statementruns a single statement and prints how long it took. Great for quick “is this line the slow one?” checks.%%time(two percent signs) at the top of a cell times the whole cell instead of one line. Useful for measuring a full data-loading or modeling step.%%timeitruns a cell many times and reports the best time, for benchmarking small pieces of code.%load_ext autoreloadfollowed by%autoreload 2sets up automatic reloading of imported modules, so edits tosrc/are picked up without restarting the kernel (see Chapter 17).%matplotlib inlinetells matplotlib to draw plots directly into the notebook instead of in a separate window. Most modern Jupyter installs do this by default, but it is occasionally needed as an explicit line at the top.
# A typical top-of-notebook setup using several magics
%load_ext autoreload
%autoreload 2
%matplotlib inline
import pandas as pd
from src.cleaning import clean_sales
%time df = pd.read_csv("data/raw/sales.csv")Safety rules for shell commands in notebooks
Shell commands inside notebooks are more dangerous than they look, because the notebook hides the usual friction of the terminal (a prompt, a clear context, a full screen of history) and makes it easier to run something destructive almost accidentally. A few rules keep the category safe.
First, treat every shell command as potentially destructive, and preview before you execute. !rm in a cell with a glob pattern is exactly as dangerous as the same command in a terminal, and has the same “run once by accident and your project is gone” failure mode. Before running any rm, mv, or redirecting > command in a notebook, run !ls or !find first to see exactly what will be affected.
Second, never use sudo from a notebook. A notebook is not the place to be making system-level changes. If you find yourself wanting to !sudo apt install something, switch to a terminal, install the package there, then come back to the notebook. The notebook’s job is data analysis, not system administration.
Third, never embed secrets — API tokens, passwords, private URLs — directly in a notebook cell. The notebook file is saved to disk with every cell’s contents intact, and when you commit it to git (or accidentally share it), whatever you typed is going with it. Load secrets from environment variables or from a .env file that is listed in .gitignore (see Chapter 34). This rule applies to both Python cells and shell cells; the file is the same.
# BAD: token is now permanently recorded in the notebook file
!curl -H "Authorization: Bearer sk-abcdef1234" https://api.example.com/data
# BETTER: token stays in the environment, never written to disk
import os
!curl -H "Authorization: Bearer $API_TOKEN" https://api.example.com/dataFourth, document what the command does in a markdown cell above it, especially for commands that are not obviously reversible. A one-sentence “This downloads the October data drop into data/raw/” is the kind of note that saves a future reader (including you) from squinting at a curl one-liner and wondering what it was for.
Finally, prefer reproducible commands over manual clicking whenever you can. The whole advantage of a notebook is that the commands are there for next time. If you find yourself running the same mouse-click sequence in a file browser on every project, turn it into a shell line in a notebook cell and document it. Next semester, you will be glad you did.
16.6 Notebook style and discipline (how to write a notebook that survives)
Structure: a notebook template
The single highest-leverage thing you can do for any non-trivial notebook is to give it a predictable structure. A reader arriving at a notebook for the first time — including you, three weeks from now — should be able to tell from the first screen what the notebook is for, what it depends on, and what it produces. The way you communicate that is by following the same skeleton every time.
# <Title>
<One-paragraph purpose: what this notebook does and why it exists.>
## Setup
- Imports
- Paths and parameters
- Smoke test (cwd, python, key files)
## Data acquisition and provenance
- Where the data came from (URL, date, source)
- How it was downloaded
## Cleaning and validation
- Filters applied (and why)
- Validation checks (row counts, required columns, no nulls)
## Analysis
- One subsection per question
## Results and interpretation
- Plots, summary tables
- One paragraph interpreting each
## Next steps / limitations
- What you did not do
- Caveats the reader should knowEach section has a purpose, and a notebook that skips sections almost always ends up confusing. The purpose paragraph is often the difference between a notebook a collaborator can understand and one they have to ask about. The setup section is where every reproducibility check lives — if the notebook is going to fail to run on someone else’s machine, it will fail here, and the failure will be obvious because this section is always the first to execute. The provenance section answers “where did this data come from?”, which is a question that has no acceptable answer later if you did not write it down at the time. The validation section catches the “wait, this shouldn’t be 0” moments while there is still time to fix them. The results section is the story you are telling; without it, the notebook is just a pile of calculations.
Use this skeleton even for small notebooks. Some sections will be two lines long. That is fine — the headings still orient the reader.
Narrative: make the notebook readable
A notebook is not a pile of code cells with gaps between them; it is a written document that happens to contain working code. The feature that makes notebooks different from scripts is the ability to interleave prose and computation, and the notebook only pays for that feature if you actually write the prose. A notebook with fifty code cells and zero markdown cells is a script with a confusing user interface.
The baseline is to use markdown headings to break the notebook into sections, with one heading per topic or phase. On top of that, write short explanatory paragraphs before any block of code that makes a decision — a filter, a join, a cutoff, a model choice. The question to answer is “why did you do it this way, not some other way?”, because six months from now you will not remember, and anyone reading the notebook fresh will want to know.
## Filtering out cancelled orders
The raw data contains every order the system has seen, including
cancellations (which appear as a separate row with `status == "cancelled"`).
For revenue analysis we want to exclude cancelled orders, because they
were refunded and no money actually changed hands. We keep them in
`data/raw/` for completeness but drop them here.
```python
active = df[df["status"] != "cancelled"]Dropping cancellations removes about 4% of rows (12,104 of 302,811).
The third piece is to **caption your plots and tables**. Every figure in a notebook should have at least a markdown cell above it that explains what you are about to see, and ideally another after it that points out what the reader should notice. A plot without a caption is decoration; a plot with a caption is evidence.
The test for whether a notebook has enough narrative is to imagine handing it to someone who knows the topic but has never seen your data. Can they read it as a document and follow the argument? If yes, the narrative is doing its job. If they would need you to sit next to them and explain, there is more prose to write.
### Reproducibility discipline
A reproducible notebook is one that produces the same outputs every time you run it from a clean kernel. That sounds obvious, but it is startlingly easy to drift away from, because the notebook UI lets you run cells out of order, delete cells whose output you still depend on, and interactively define variables that never make it into any cell. The defense is a short list of habits that, taken together, keep the notebook honest.
The first habit is to **use a consistent top-to-bottom execution order** and never run a cell that depends on something further down in the notebook. The execution counts in the cell margins should go `[1] [2] [3] [4]` straight through. If you catch yourself running cells out of order — especially to "just check something" — fix the order immediately while you remember, instead of leaving a landmine for the next run.
The second habit is to **periodically Restart Kernel and Run All**. Not just before you hand the notebook in — during the work too, every time you finish a major change. This is your early warning system for hidden-state bugs. If the notebook works interactively but fails on a restart, something you deleted, renamed, or moved is still silently present in the kernel's memory and will disappear on the next launch. Better to find out now than later.
```text
Kernel → Restart Kernel and Run All CellsThe third is to avoid hidden dependencies on prior interactive state. If you typed a variable definition into the kernel directly (via %debug, %debug continuation, or an exploratory df2 = df.copy() you ran and then deleted), it will still exist in the current session but not in any future one. Every variable the notebook uses should be defined by some cell that is currently in the notebook.
The fourth is to prefer functions over repeated copy/paste code. Every time a block appears in two cells, it is a silent invitation for the two copies to drift apart. Extract it into a helper function — either in src/ or in a cell near the top of the notebook — and call it in both places.
The fifth is to prefer relative paths inside a project. A notebook that reads /Users/alex/Downloads/survey.csv runs only on Alex’s laptop; a notebook that reads data/raw/survey.csv runs anywhere the same project folder exists. This is the same advice you have now seen in three chapters, because it is the single biggest portability improvement you can make.
Environment capture (student level)
The code in your notebook is only half of what determines its behavior; the versions of Python and every installed package are the other half. A notebook that uses pandas 2.0 behaves subtly differently from one that uses pandas 1.3. If you do not record which versions were in play when the notebook was written, reproducing your results six months later becomes an archaeology problem.
The student-level habit is to record the key versions directly in the notebook, as part of the smoke-test cell:
import sys, platform
import pandas as pd, numpy as np
print("python: ", sys.version.split()[0])
print("platform:", platform.platform())
print("pandas: ", pd.__version__)
print("numpy: ", np.__version__)The professional-level version is to maintain an environment file in the project that pins every dependency (see Chapter 15 and Chapter 14). For a conda environment, that file is environment.yml; for a pip-based virtual environment, it is requirements.txt or a pyproject.toml. Whichever you use, commit it to version control alongside the notebook, and write one line in the README.md explaining how to recreate the environment from it. With an env file plus the code, anyone — including you on a new machine — can get back to the exact same stack and reproduce the results.
Also worth doing as a matter of hygiene: keep datasets and generated artifacts in well-labeled folders rather than scattered around the project. data/raw/ for inputs, data/processed/ for derived tables, figures/ for plots, reports/ for finished artifacts. A notebook that writes everything to the current directory is harder to clean up and harder to audit than one whose outputs land in predictable places.
Outputs and size control
Notebooks store their outputs inside the file itself, and if you are not careful, a notebook that prints and plots generously can balloon to tens or hundreds of megabytes. A large notebook is slow to open, painful to scroll, and nearly impossible to review in git — most code-review tools simply refuse to display diffs over a certain size.
The first preventative habit is to avoid embedding huge binary blobs. A cell that plots 100,000 points with matplotlib produces a PNG that gets base64-encoded and stuffed into the .ipynb file. If you regenerate the plot twenty times while iterating, and you never clear the old outputs, all twenty versions accumulate in the file. The fix is to periodically Cell → All Output → Clear, then rerun only what you need, so the saved notebook contains one copy of each plot, not twenty.
The second habit is to save outputs to files instead of embedding them, for anything that is going to be shared outside the notebook. A figure that matters belongs in figures/ as a PNG or SVG, referenced from a markdown cell — not embedded in the cell output. A cleaned dataset belongs in data/processed/ as a CSV or Parquet file, with the notebook serving as the recipe that produces it.
# Avoid: 4 MB PNG stored inside the notebook file
import matplotlib.pyplot as plt
plt.scatter(x, y)
plt.show()
# Prefer: saved to a file, referenced from markdown
fig, ax = plt.subplots()
ax.scatter(x, y)
fig.savefig("figures/scatter-by-region.png", dpi=150, bbox_inches="tight")
plt.close(fig) # prevents the figure from also appearing in the cell outputThe payoff is that the notebook stays small (its job is to produce artifacts, not to be them), version control behaves sensibly, and the artifacts themselves are first-class files you can share or embed in a report.
16.7 Notebook pitfalls and how to prevent them
Out-of-order execution
The classic notebook bug is the one where everything works in the current session and nothing works anywhere else. You run cell 7, then cell 3, then cell 5, then cell 8, you get the answer you wanted, and you close the laptop. Next week the same notebook throws NameError: x is not defined on the first run from the top, because cell 8 referenced a variable that only existed in the kernel because you happened to have run cell 3 a minute earlier. This failure mode is called out-of-order execution, and it is by far the most common way a notebook “works on my machine” and nowhere else.
The signal that out-of-order execution has happened is right there on every code cell: the execution count in square brackets. If the counts down the notebook go [1] [2] [3] [4] [5], the cells were run in order. If they go [5] [1] [7] [2] [6], they were not, and anything that worked under those circumstances was an accident you should not rely on.
# Cell execution counts in a healthy notebook
[1] import pandas as pd
[2] df = pd.read_csv("data/raw/sales.csv")
[3] df = df.dropna(subset=["amount"])
[4] df["year"] = df["date"].dt.year
[5] df.groupby("year")["amount"].sum()
# Cell execution counts in a notebook with a hidden-state bug
[3] import pandas as pd
[1] df = pd.read_csv("data/raw/sales.csv")
[5] df["year"] = df["date"].dt.year # needed cell [2] first
[2] df["date"] = pd.to_datetime(df["date"])
[4] df.groupby("year")["amount"].sum()The prevention is the ritual we have come back to several times: Kernel → Restart Kernel and Run All Cells, every time you finish a chunk of work. Restart wipes the kernel, run-all executes the whole notebook top to bottom, and if everything still works, your notebook is actually reproducible. If anything breaks, you have just caught a bug that would otherwise have surfaced at the worst possible moment — on a grader’s machine, or the night before a deadline.
Wrong kernel / wrong environment
The second most common failure has a different symptom: you open a notebook you were working on yesterday, import pandas, and get ModuleNotFoundError. Or the import works, but a function that should exist is missing because the version is wrong. Or a cell you have run a hundred times suddenly produces a deprecation warning it never did before. All three are versions of the same problem: the kernel the notebook is using is not the Python environment you think it is.
Jupyter lets you have multiple Python environments registered as separate “kernels,” and it is easy to accidentally pick the wrong one — especially after creating a new virtual environment, switching branches, or opening a notebook that was originally written against a different environment. The kernel name in the top-right corner of the notebook tells you which one is active; the Kernel → Change kernel menu lets you switch.
The prevention has two parts. First, name your kernels clearly when you register them. When you use python -m ipykernel install --user --name=info3010 --display-name="INFO 3010 (venv)", the kernel shows up as “INFO 3010 (venv)” in the menu, which is much easier to pick than “Python 3 (ipykernel)” — the default name that every environment gets by default and that tells you nothing.
# Register the project's venv as a named kernel
$ source .venv/bin/activate
(.venv) $ python -m ipykernel install --user \
--name=info3010 --display-name="INFO 3010 (venv)"Second, confirm the environment in a top-of-notebook cell every single time. The smoke-test cell (see Chapter 17) should print sys.executable and the versions of any packages the notebook cares about:
import sys
print("python: ", sys.executable)
import pandas as pd
print("pandas: ", pd.__version__)If the interpreter is not the one from your project’s virtual environment, the kernel is wrong, and no amount of pip-installing will help until you switch kernels.
File not found (paths)
The third common pitfall is the FileNotFoundError that makes no sense because the file is right there. You can see data/raw/sales.csv in the Jupyter file browser. You can open it in another tab. But pd.read_csv("data/raw/sales.csv") in a code cell produces FileNotFoundError: [Errno 2] No such file or directory: 'data/raw/sales.csv'.
The cause is almost always that the kernel’s working directory is not where you think it is. A relative path like data/raw/sales.csv is resolved from the kernel’s current working directory, not from the folder the notebook file lives in. If you launched Jupyter from your home directory and the notebook happens to live three folders deep, the kernel’s CWD is your home directory, not the project root, and data/ is not there at all.
The diagnostic is three lines:
import os
from pathlib import Path
print("cwd: ", os.getcwd())
print("exists: ", Path("data/raw/sales.csv").exists())
print("absolute:", Path("data/raw/sales.csv").resolve())If cwd is not the project root, the fix is to restart Jupyter from the right folder (recommended) or to %cd to the project root in the first cell (okay for one-off work). If exists is False and absolute shows an unexpected path, you now know exactly where the kernel was looking and can fix either the CWD or the path.
The longer-term prevention is the one from Chapter 10 and Chapter 17: keep a stable project root and always launch Jupyter from it, so paths never depend on where the server was started.
Long-running or stuck cells
Eventually a cell takes longer than you expected — a data load that should take ten seconds is still running after two minutes, or a training loop that should finish in five minutes is showing no sign of stopping. The first question to ask is whether the cell is slow (doing the work, just taking a while) or stuck (hung on something that will never finish).
The first line of defense is Interrupt (the square “stop” button in the toolbar, or I, I in command mode). Interrupt asks the kernel to stop whatever the current cell is doing while keeping all the variables you have built up so far. If the cell was truly stuck — on a broken network call, a deadlock, an infinite loop — interrupt usually returns control in a second or two. If the cell was busy doing real work, interrupt may take longer to take effect because the kernel can only respond between Python operations.
If interrupt does not work, the next step is Restart (Kernel → Restart Kernel, or 0, 0 in command mode). Restart kills the kernel outright and boots a fresh one — any in-progress work is discarded, and all the variables you had built up are gone. Restart is the nuclear option; use it only after interrupt has failed.
The prevention is to add visibility to any cell that might take more than a few seconds. For loops, use tqdm to show a progress bar so you can tell whether it is actually making progress:
from tqdm import tqdm
for row in tqdm(df.itertuples(), total=len(df)):
process(row)For a single operation whose duration you want to measure, use %time or %%time at the top of the cell:
%%time
result = expensive_function(df)With a progress bar or a timer, “is it actually stuck?” becomes “how fast is it going?”, which is a much more useful question to ask.
The structural prevention is to move expensive work out of notebooks and into scripts whenever it is genuinely expensive. A model that takes four hours to train does not belong in a notebook cell where the slightest mistake costs you the whole run. Put the training in a script that writes the model to disk, then have the notebook load the saved artifact and analyze it. Notebooks are for interactive exploration; anything that takes longer than the time you are willing to sit and wait should live somewhere else.
16.8 When to move from notebooks to scripts (and back)
Chapter 17 covers the scripting workflow in full; this section explains how notebooks and scripts fit together and when to use which.
Notebook strengths
Notebooks shine when the primary goal is exploration, explanation, or sharing results. The mix of code, prose, and inline outputs is the whole point — it is what lets you try something, see the result immediately, write a sentence explaining what you are seeing, and try the next thing. A notebook is a document with live computation inside it, and no other tool quite captures that combination.
Concretely, reach for a notebook when you are still figuring out what the data looks like and the question is still changing. When you are iterating rapidly between a line of code and a plot. When the final artifact is a written analysis that someone else will read — a short report, a homework submission, a stakeholder briefing with embedded figures. When the value is in the explanation, not the execution.
Script strengths
Scripts shine when the primary goal is repeatable execution. The same code, applied to (possibly different) inputs, with no human sitting in front of the keyboard, producing reliable outputs in predictable places. Scripts are what you run in batch jobs, in cron schedules, in continuous integration pipelines, in containers, on remote servers you cannot see. They are the right shape for any work that needs to happen regularly, unattended, or over many inputs.
Concretely, reach for a script when the analysis has stabilized and you need to run it again. When the work needs to happen on a schedule (every morning at 6 AM, every time new data arrives). When you want version control to produce meaningful diffs. When you need parameters (a date range, a file path, a model configuration) to change between runs without editing code. When the value is in the execution, not the explanation.
A practical boundary for students
In real projects the right answer is almost never “notebook only” or “script only” — it is a layered combination where each tool does what it is best at. The practical boundary for most student work has three layers:
Keep exploration in notebooks. This is where you poke at the data, try visualizations, write hypotheses in markdown, and discover what the analysis should actually do. Early notebooks are messy, and that is fine — they are scratch paper, not deliverables.
Extract stable logic into
src/as functions. Any block of code you find yourself copying into a second notebook, or tweaking for the fourth time to debug something, should become a function insrc/. The notebook goes from holding ten lines of cleaning code to holding one line that callsclean_sales(df), and the function can be reused in other notebooks and scripts.Keep the notebook as a narrative driver that calls those functions. Once the logic lives in
src/, the notebook’s job is to tell the story: load the data, call the cleaning function, show the results, explain what they mean. The notebook is short, readable, and focused on interpretation; the heavy lifting happens in imported code that can be reused and unit-tested.
notebooks/
└── 01-explore.ipynb ← narrative + plots + interpretation
src/
├── cleaning.py ← pure functions, imported by both the notebook
├── modeling.py and the CLI script
└── plotting.py
scripts/
└── run_pipeline.py ← batch entry point, imported by nothing,
runs the same src/ functions from the command lineThe notebook and the script import the same functions from src/. When you improve a cleaning step, both the notebook and the script pick up the improvement automatically, because there is only one copy of the logic. This is the shape that “scales”: small student projects can start with just a notebook, grow to need src/ as they get more complex, and grow again to include scripts/ when they need automation — without ever having to rewrite from scratch.
16.9 Stakes and politics
Notebooks are unusual in that they look like the most transparent computing artifact possible — code and output side by side, ready to read — but they have political dimensions that the appearance hides. Two things to notice. First, the reproducibility theatre. A notebook that displays a clean run from top to bottom can have been produced by any sequence of cell executions, with any history of variables in memory, against any version of any package. The very feature that makes notebooks teachable — you can see the answer right there — also makes them easy to share in a state nobody can rerun. “Reproducible” notebooks require explicit work that is not visible in the notebook itself: pinned environments, raw-data provenance, “Restart kernel and run all” before every save. Without that work, the notebook is closer to a screenshot than a program.
Second, the data leak that comes free with df.head(). Notebook cells routinely display real rows of real datasets — names, identifiers, free-text comments — directly inside the file. When a notebook is committed to a public GitHub repo or pasted into a forum for help, those rows go with it. The convenience of inline output is a privacy hazard the format does not warn you about.
See Chapter 8 for the broader framework. The concrete prompt to carry forward: before you share a notebook, ask whether someone could rerun it from scratch, and whether anything in its output should not have left your laptop.
16.10 Worked examples
Launching Jupyter in the right place
You have a project at ~/Courses/INFO-3010/Project and you want to start a notebook session for it. The full sequence:
$ cd ~/Courses/INFO-3010/Project
$ source .venv/bin/activate
(.venv) $ jupyter lab
[I 2026-04-10 12:34:56.789 ServerApp] http://localhost:8888/lab?token=abc...Click the URL Jupyter prints (or it will open automatically), then create a new Python 3 notebook. In the first cell, confirm you are where you think you are:
import os, sys
print("python:", sys.executable)
print("cwd:", os.getcwd())
print("files:", sorted(os.listdir("."))[:5])Expected output (paths abbreviated for clarity):
python: /Users/you/Courses/INFO-3010/Project/.venv/bin/python
cwd: /Users/you/Courses/INFO-3010/Project
files: ['README.md', 'data', 'notebooks', 'src']If all three lines look right — the Python is from your project’s venv, the cwd is the project root, and the files include what you expect — you are ready to work.
Debugging “no files”
You open JupyterLab and the file browser shows your home directory instead of your project. Stop the server (Ctrl+C in the terminal twice), then reopen the terminal:
$ pwd
/Users/you # the wrong place
$ cd Courses/INFO-3010/Project
$ source .venv/bin/activate
(.venv) $ jupyter labNow the file browser shows the project, and the working-directory check cell from the previous example confirms it. The whole fix is “go to the right folder before starting the server,” which is also why the previous example put cd first.
Making a notebook reproducible
A notebook that runs once but fails on a clean kernel is not really finished. Three habits make a notebook genuinely reproducible. The first is to give it a clear linear structure: a title in a markdown cell, a one-paragraph purpose statement, then an “imports and setup” code cell, then the analysis cells in execution order, then a “results” section. The second is to extract any logic that you might want to reuse into functions in src/, and import them rather than copy-pasting code between cells. The third is the discipline of Restart Kernel and Run All every time you finish a meaningful chunk of work — and especially before you commit the notebook to git or share it with anyone. If “Restart and Run All” produces an error that interactive use never did, you have just discovered a hidden-state bug, and now is the right time to fix it. Better to find it now than to ship a notebook that quietly does not reproduce.
16.11 Templates
Template A: Notebook header block
Title:
Author:
Date:
Purpose:
Data sources:
Environment:
* Python:
* Key packages:
How to run:
* Restart kernel and Run All
Outputs:
* Where figures/tables are savedTemplate B: Reproducibility checklist cell
# Reproducibility check
# 1) print working directory
# 2) print python and package versions
# 3) confirm data files exist
# 4) run a small smoke test16.12 Exercises
16.13 One-page checklist
I launch Jupyter from the correct project folder (or pass the correct directory).
I can diagnose “no files” as a working-directory/server mix-up.
I understand kernels and can choose the correct one.
I use markdown headings to structure the notebook.
I keep a top-to-bottom execution order and periodically restart-and-run-all.
I use shell commands and magics sparingly, with explanations and no secrets.
I record environment details and keep data provenance explicit.
I keep outputs controlled and store large artifacts outside the notebook.
16.14 Quick reference: common launch and debugging moves
Confirm working directory before launching.
If you see the wrong files: stop server, relaunch in correct directory.
If imports fail: check kernel/environment.
If execution hangs: interrupt; then restart if needed.
16.15 Quick reference: IPython conveniences
- Project Jupyter, JupyterLab documentation — the official guide to the multi-document interface, extensions, and kernels.
- Project Jupyter, Jupyter Notebook documentation — the classic single-document interface, still widely used in courses.
- IPython, IPython documentation — the kernel underneath every Python notebook; learn its
?,??,%timeit, and%debugmagics and you will spend less time reaching for separate tools. - Joel Grus, I Don’t Like Notebooks (JupyterCon 2018) — a sharp, well-known critique of notebook workflows; worth knowing the arguments even if you keep using notebooks.
- Mahmoud Hashemi,
nbstripout— a tool that strips notebook output before commit; the simplest defense against leaking inline data into a Git history. - nteract, Papermill — a tool for parameterizing and executing notebooks from the command line; turns a notebook into something closer to a reproducible pipeline.
- Project Jupyter, Jupyter Governance — the project’s governance documents; useful context when you wonder who actually decides where the platform goes next.
